• Model NO.：HY-CB55C
• Coating：Painting
• Airflow Direction：Fully Undershot-type
• Heating Mode：Electric
• Paint Mist Treatment：Dry-type
• Condition：New
• Color：White, Red, Blue
• Size：6900*3900*2700
• Wall Panel：50 mm EPS Foam Panel
• Ceiling Panel：Galvanized Steel, EPS Panel for Option
• Intake Fan：2sets
• Exhaust Fan：1set
• Heating System：Electricity
• Total Power：13kw
• Control Box：English Panel
• Drawing：Available
• Control：Automatic
• Related Product 1：Large Truck Paint Spray Booth
• Related Product 2：Furniture Paint Spray Booth
• Related Product 3：Folding Retractable Paint Spray Booth
• Related Product 4：Wet Type Water Curtain Paint Spray Booth
• Transport Package：Standard Package for Sea Shipment
• Specification：26 cbm for FCL
• Trademark：N,A
• Origin：China
• Production Capacity：100 Set Per Month

Basic Info.

Model NO. HY-CB55C Coating Painting Airflow Direction Fully Undershot-type Heating Mode Electric Paint Mist Treatment Dry-type Condition New Color White, Red, Blue Size 6900*3900*2700 Wall Panel 50 mm EPS Foam Panel Ceiling Panel Galvanized Steel, EPS Panel for Option Intake Fan 2sets Exhaust Fan 1set Heating System Electricity Total Power 13kw Control Box English Panel Drawing Available Control Automatic Related Product 1 Large Truck Paint Spray Booth Related Product 2 Furniture Paint Spray Booth Related Product 3 Folding Retractable Paint Spray Booth Related Product 4 Wet Type Water Curtain Paint Spray Booth Transport Package Standard Package for Sea Shipment Specification 26 cbm for FCL Trademark N/A Origin China Production Capacity 100 Set Per Month

Product Description

Introduction of the Auto paint spray booth for car and minivan with diesel Burner
1. full-down draft paint booth:
2. semi-down draft paint booth:
3. side-down draft paint booth:
4. cross-draft paint booth:

Quick Specification of the Auto paint spray booth for car and minivan with diesel Burner

Model	HY-CB55C
Outside Size(mm)	7000(L)*4000(W)*3400(H)
Inside Size(mm)	6900(L)*3900(W)*2700(H)
Front Door(mm)	3000*2600(W*H)
Side Door(mm)	650*2000(W*H)
Total power	<17kW
Voltage status	380V/3ph&220V/1ph@50Hz
Wall Panel	50mm EPS foam panel
Ceiling panel	Galvanized steel
Basement&floor	Raised metal-base (300mm high) with complete grating floor.
Intake	TWO set of fan, motor: 4kW.
Exhaust	One set of fan, motor: 5.5kW.
By-pass	Pneumatic damper from spraying to baking cycle
Heating System(Oil)	electric heaters
Filter System	4 stages of filters: Pre-filter, ceiling filter, floor paint-stop filter, extract paint-stop filter
Lighting	Upper lights, 8units, 4*36W each.
Control System	1set.

Picture of the Auto paint spray booth for car and minivan with diesel Burner and heat insulation panel
Project case for paint booth


Package show

Production area and equipment show


Certificate of our product and company

Our Team is serving you at any time
