Vehicle Repair Equipment & Tools

C953 Economic Car Tyre Changer 10-21" Pneumatic Car Reparing Garage Equipment

Yingkou Yuanmech Machinery Co., Ltd.
  • Warranty:14 Months
  • Structure:Vertical

Base Info

  • Model NO.:C953
  • Power Source:Pneumatic
  • Type:Simple Disassembly
  • Automatic:Semi-Automatic
  • Standard:Standard
  • Certification:CE
  • Condition:New
  • Product Name:Hot Deals Motorcycle Tire Changer Machine
  • Working Pressure:8-10bar,117-145psi
  • Outside Clamping:10-19"
  • Inside Clamping:12-21"
  • Max. Wheel Width:3-12"
  • Max. Wheel Diameter:1000mm
  • Bead Breaker Force:2500kg
  • Color:Customized Color Acceptable
  • Machine Weight:N.W:195kg G.W:205kg
  • Optional Specifications 1:Optional Different Kinds of Front Cover
  • Optional Specifications 2:Optional Different Kinds of Pneumatic Locking
  • Optional Specifications 3:Optional Different Kinds of Inflation Gun
  • Optional Extra Accessory1:Motorcycle Adaptor
  • Optional Extra Accessory2:Bead Blaster Function
  • Optional Extra Accessory3:Leverless System
  • Transport Package:Plywood
  • Specification:980*760*950mm (870mm)
  • Trademark:YuanMech
  • Origin:Yingkou, Liaoning, China
  • HS Code:8479899990
  • Production Capacity:3000PCS,Month
  • Package size per unit product:98.00cm * 76.00cm * 95.00cm
  • Gross weight per unit product:205.000kg

Description

 C958C958   24"        C9582   24"     Two Point Pressure Right Helper   C9583   24"      Three Point Pressure Right Helper  C9582S   24"Leverless    Two Point Pressure Right Helper   C9583S   24"Leverless     Three Point Pressure Right Helper    C953 Economic Car Tyre Changer 10-21" Pneumatic Car Reparing Garage EquipmentC953 Economic Car Tyre Changer 10-21" Pneumatic Car Reparing Garage EquipmentC953 Economic Car Tyre Changer 10-21" Pneumatic Car Reparing Garage Equipment
C953 Economic Car Tyre Changer 10-21" Pneumatic Car Reparing Garage Equipment



1. Why is filter-regulator (FRL) so important?
It dry the air so there is no moisture inside pneumatic components. It lubricates the rubber seals to extend its service life. In general FRL is important to maintain long service life of the machine.
2. When working table doesn't turn, how to determine if the problem comes from gearbox, motor or switch?
Disconnect belt and see if the motor can run properly. If not, test the motor itself to see clockwise rotation and anti-clockwise rotation. If motor running properly then the problem is the switch.
We have trouble shooting in details, please contact us for more information.
3. When working table doesn't have needed power to clamp the rim, how to trouble shooting if the problem comes from table cylinder, turning air distributor or pedal valve?
When the cylinder not strong enough, there could be air leaking. The leaking could be on the covers or internal piston. There is a systematic method to trouble shoot, please contact us if you are interested in how to trouble shoot.
