Motorcycle Dynamic Balancing Machine Automobile Tire Tester
Yingkou Yuanmech Machinery Co., Ltd.- After-sales Service：Video Call, Online & Face to Face Service and Trai
- Warranty：14 Months
- Balancing Type of Wheel：Off-Car Type
- Balancing Range：Small Size Wheel
- Design Type：Horizontal Type
- Function：Dynamic Balance, Static Balance, Wheel Balance, Motorcycle Balance, Well Balanced, Auxiliary Implicit Procedure, Calibration Procedure
Base Info
- Model NO.：B656M
- Working Noise：<70db(A)
- Condition：New
- Certificate：CE Certificate
- Power：250W
- Balancing Speed：200 R,Min
- Motor Power：110V,220V,240V, 50Hz,60Hz
- Rim Diameter：10-28"
- Max Wheel Diameter：1000mm
- Max. Wheel Weight：70kg
- Rim Width：1.5-20"
- Calibration Wheel：15" Steel Rim Wheel
- Max Wheel Weight：70kg
- Machine Weight：N.W:105kg G.W:120kg
- Packing Size：1000*650*1160mm
- Optional Specifications 1：Optional Pedal Brake
- Optional Specifications 2：Optional Laser Light
- Optional Specifications 3：Optional Motorcycle Adaptor
- Transport Package：Plywood
- Specification：1000*650*1160mm
- Trademark：YuanMech
- Origin：Yingkou, Liaoning, China
- HS Code：9031100090
- Production Capacity：3000PCS,Month
Description
1. What are common problem when using motorcycle adaptor?
The common problem with motorcycle/adaptor is the shaft strength. With heavy or big wheel, the thin shaft jumps during rotation, which cause a bad balancing result. (Please contact us if you have more questions on this topic)
2. How does the material (Fe or Pb) of balancing weight affect balancing result?
Two weight materials, Ferrous or Lead. The two materials have different density, so the center of mass is different. (Please contact us if you have more questions on this topic)
3. How does the wheel balancer work? What are the functions of the main components?
Piezoelectric sensor get "vibration" signal and send it to CPU. Encoder board get "position" signal and send it to CPU. CPU calculate imbalance based on these signals, wheel dimensions and balancing mode. (Please contact us if you have more questions on this topic)
