• Model NO.：EXD
• Certification：CCC, CE, GS, SGS
• Substrate：Steel
• Brand：Captain
• Coating：Painting
• Airflow Direction：Fully Undershot-type
• Heating Mode：Diesel
• Paint Mist Treatment：Dry-type
• Condition：New
• Inside Dimension：6900*4000*2600mm(L*W*H)
• Outside Dimension：7000*5600*3250mm(L*W*H)
• Main Door：3-Fold, 2700*2500mm(W*H)
• Personal Door：1-Fold, 650*1800mm (W*H)
• Wall Panel：50mm EPS with 0.5mm Steel
• Basement and Floor：2 Rows Grilles, 3 Rows Diamond Plate
• Lighting System：24PCS Ceiling Lights, 16PCS Side Lights
• Intake Fan：2*4kw Double-Intake Centrifugal Fan
• Exhaust Fan：1*4kw Double-Intake Centrifugal Fan
• Heating System：Italian Riello G20 Diesel Burner
• Transport Package：Export Container ,Pallet ,Disassembly with Carton
• Specification：CE, SGS
• Trademark：OEM,Captain
• Origin：Shandong, China.
• Production Capacity：96sets,Month
• Package size per unit product：7000.00cm * 5600.00cm * 3250.00cm
• Gross weight per unit product：3500.000kg

Booth SystemWall panel :EPS(epispastics polystyrene) heat preservation panel doubleskinned ,
 tongue and groove construction, thickness: 50MM EPS.Basement and floor: Complete steel assemble, height: 300mm. 2 rows of grids,
 3 rows of embossed plates. 2Pcs ramps, each size:700X1800MM(WXL)Lighting SystemCeiling light: 3Pcs X8units=24PcsX36W, Lower light: 2Pcs X8units=16PCsX30W,
 vertical installation. Phillip brand light tube with PAK light holderGenerator setting typeSide upper intake air, quadrate steel frame, coated steelVentilation SystemIntake fan:2X4KW double-intake centrifugal fan, , air capacity:22000m3 /hExhaust fan: 1Pc 4KW double-intake centrifugal fan, air capacity:12500m3 /hHeating systemItalian Riello G20 diesel burner, 200000Kcal, 4~6kg/set; heating-up time: 6~8 min. Gas burner as optionalSUS304 Stainless steel heat exchanger, highest temperature 80C, 1pc electric damper from spraying to baking cycle. Reasonable structure, safe and reliable, big heat exchanging area, high heat utilization, more than 87.1% heat exchanging rateFilter systemPrefilter, high efficiency filte (ceiling filter),
 floor filter, exhaust active carbon filterControl systemSpraying, risen-temperature spraying, baking temperature, time setting,
 lighting switch, emergency stop, failure indicator, limited-temperature
 deviceTotal power14KW14 KW
