Ce Certified 5.5t 4 Post Car Lift (409A)

PEAK CORPORATION
  • Type：Four Cylinder Hydraulic Lift
  • Lifting Capacity：5.5t
  • Driving Type：Hydraulic
  • Certification：CE
  • Driving Motor Number of Mechanical Lift：1
  • Condition：New

Base Info

  • Model NO.：409A
  • Brand：Peak
  • Design：Four Post
  • Color：Blue
  • Surface Treatment：Spray-Paint
  • Lifting Time：60 Seconds
  • Lifting Height：1915mm(75 2,8")
  • Motor：4.0HP
  • Gross Weight：1326kg(2,923lbs)
  • Transport Package：Iron Bracket
  • Specification：12000LBS
  • Trademark：PEAK
  • Origin：Foshan, China
  • HS Code：8425429000
  • Production Capacity：30000sets,Year

Description

ModelLifting Capacity4094.0T (9,000 lbs)409A4.0T (9,000 lbs)4125.5T (12,000 lbs)412A5.5T (12,000 lbs)4146.5T (14,000 lbs)414A6.5T (14,000 lbs)* "A" with alignment function.
Ce Certified 5.5t 4 Post Car Lift (409A)Ce Certified 5.5t 4 Post Car Lift (409A)Ce Certified 5.5t 4 Post Car Lift (409A)Ce Certified 5.5t 4 Post Car Lift (409A)Ce Certified 5.5t 4 Post Car Lift (409A)Ce Certified 5.5t 4 Post Car Lift (409A)

Feature
• Electric-air control operation system.
• Mechanical self-lock and air-drived safety release.
• Electrical hydraulic power system, cable-drived.
• Non-skid diamond platform.
• Adjustable platform and adjustable safety lock ladders.
• Two adjustable turntable positions to fit the different wheel base.
• Dual safety device: In case the primary safety locks are out of operation,the lift would also be locked automatically by a second safety device.
• Optional Jack: J6H (hand pump), J6A (SPX Air pump) and include 1.5", 2.5" extension adapters.
• Long warranty:
5 Years warranty on lift structure(including Columns, Carriage, Lifting Arms, Top Beam, Floor Cover, Platform, Cross Beam, Car Drive-in Ramp, Scissor, Baseframe etc.);
2 Years warranty on the hydraulic parts (including cylinders, oil seal, oil hose, fitting etc.);
1 Year warranty on the spare parts, electrical components, power unit (not including consumption parts such as rubber pad).


CE Certified 5.5t 4 Post Car LiftModel412AStyleAlignment Four Post Car LiftLifting Capacity5.5T (12,000lbs)Lifting Time60 SecondsAOverall Length (With Ramps)6012mm (236 5/8")BOverall Length (No Ramps)5100mm(200 3/4")COverall Width3208mm(126 1/4")DWidth Between Columns2852mm(112 1/4")ELifting Height1900mm(75")Gross Weight1319kg(2,908lbs)Motor4.0HPPacking Dimension5170 X 560 X 720 mmQTY of Container12 Units/20'GP24 Units/40'GP
