Prep Station Room for Car Repair Workshop

Shandong Longxiang Machinery Co., Ltd.
  • After-sales Service：1 Year
  • Warranty：1 Year
  • Type：Preparation
  • Certification：CE
  • Substrate：Steel
  • Brand：Longxiang Brand

Base Info

  • Model NO.：LX-6100
  • Coating：Powder Coating
  • Airflow Direction：Cross-flow Type
  • Heating Mode：Without Heating
  • Paint Mist Treatment：Dry-type
  • Condition：New
  • Inside Dimension：6300*3450*2800mm(L*W*H)
  • Outside Dimension：7550*3550*3200mm(L*W*H)
  • Basement：Without Basement
  • Fan System：Centrifugal Fan
  • Lighting System：LED Lighting
  • Voltage：380V,220V
  • Total Power：6.4kw
  • Usage：Car Polishing
  • Name：Prep Station
  • Filtering System：Fiber Glass Filter
  • Transport Package：Sea Package
  • Specification：7550*3550*3200mm(L*W*H)
  • Trademark：longxiang brand
  • Origin：China
  • HS Code：8419899090
  • Production Capacity：30 Sets,Months

Description

                     Specification of Prep-station (LX-6100)        Inside dimension6300×3450×2800mm(L×W×H)Outside dimension7550×3550×3200mm(L×W×H)Basement and floorWithout basementCeiling system6400×3550×520mm(L×W×H),with coaming all sides,lighting between the coaming along the length.The back section of the ceiling is sealed by seal plateGenerator setting typeRear exhaust;square tube frame;white color coated steelExhaust systemGenerator cabin dimension:2290×1200×1800mm(L×W×H);5.5KW one set inner motor centrifugal fan with air capacity 16000m³/h,belt-drive,electric damper to control the air inlet and outlet volumeSeal typeBack side set 50mm EPS,other 3 sides with PVC soft curtain,curtain color:upper part:white,middle part:transparent,lower part:whiteCeiling installationSteel rope hanging or steel pole supporting the roof(optional)Filter systemFiberglass filterLighting system8 units×3pcs=24×36W;side lightsControl systemFan switch,lighting switch and electric damper switchVoltage frequency380V/3PH or 220V/1PH,50HZTotal power 6.4KW
