• Model NO.：HY-CB55A
• Coating：Painting
• Airflow Direction：Cross Draft
• Heating Mode：Diesel
• Paint Mist Treatment：Dry-type
• Condition：New
• Color：Red, Blue, White
• Size：7000*4000*3500mm
• Total Power：28kw
• Wall Panel：50mm EPS Foam Panel
• Intake Fan：2sets
• Exhaust Fan：1set
• Filter System：4-Stage Filtration System
• Heat System：Gas, Diesel, Electric, Oil, Waste Oil
• Light System：Upper Lights
• Control System：English Panel
• Transport Package：Standard Package for Sea Shipment
• Specification：40 GP for FCL
• Origin：China
• Production Capacity：100 Set Per Month

Basic Info.

Model NO. HY-CB55A Coating Painting Airflow Direction Cross Draft Heating Mode Diesel Paint Mist Treatment Dry-type Condition New Color Red, Blue, White Size 7000*4000*3500mm Total Power 28kw Wall Panel 50mm EPS Foam Panel Intake Fan 2sets Exhaust Fan 1set Filter System 4-Stage Filtration System Heat System Gas, Diesel, Electric, Oil, Waste Oil Light System Upper Lights Control System English Panel Transport Package Standard Package for Sea Shipment Specification 40 GP for FCL Origin China Production Capacity 100 Set Per Month

Product Description

Introduction of the bus spray booth for bus painting and curing
1. full-down draft paint booth:
2. semi-down draft paint booth:
3. side-down draft paint booth:
4. cross-draft paint booth:

Model	HY-CB55A
Outside Size(mm)	7000(L)*4000(W)*3400(H)
Inside Size(mm)	6900(L)*3900(W)*2700(H)
Front Door(mm)	3000*2600(W*H)
Side Door(mm)	650*1800(W*H)
Total power	<15kW
Voltage status	380V/3ph&220V/1ph@50Hz
Wall Panel	50mm EPS foam panel
Ceiling panel	Galvanized steel
Basement&floor	Raised metal-base (300mm high) with 2rows of grates and 3rows of diamon plates.
Intake	Two set of fan, motor: 4kW.
Exhaust	One set of fan, motor: 5.5kW.
By-pass	Pneumatic damper from spraying to baking cycle
Heating System(GAS)	Italy Riello FS10/FS20 gas burner,  one-stage oil burner/electricity for option.
Filter System	4 stages of filters: Pre-filter, ceiling filter, floor paint-stop filter, extract paint-stop filter
Lighting	Upper lights, 8units, 4*36W each.
Control System	1set.

Parts view of the paint booth

parts show of the Common Type Car Paint Booth





Project case for paint booth



Certificate of our product and company
