• Model NO.：209CH
• Condition：New
• Brand：Peak
• Design：Two Post
• Lifting Time：52 Seconds
• Lifting Height：1815-2044mm(71 1,2"- 80 1,2")
• Motor：2.0,3.0HP
• Gross Weight：701kg(1,545lbs)
• Color：Blue
• Surface Treatment：Spray-Paint
• Transport Package：Iron Bracket
• Specification：9000LBS
• Trademark：PEAK
• Origin：Foshan, China
• HS Code：8425429000
• Production Capacity：30000sets,Year

ModelLifting Capacity209C4.0T (9,000 lbs)209CH4.0T (9,000 lbs)* "C" is planer-type style.
* 209CH is higher than 209C.

Feature
• 9,000 Lbs Capacity
• Dual hydraulic cylinders, designed and made on ANSI standard, high quality NOK seals.
• 3/8" aircraft quality cable is used for synchronization.
• Supersymmetric arms design with three-stages front arms and two-stages rear arms.
• Self-lubricating UHMW Polyethylene sliders and bronze bush.
• Single-point safety release, and dual safety design.
• Clearfloor design, provide unobstructed floor space.
• Overhead safety shutoff device.
• Stackable rubber pad with 1.5", 2.5" and 5" extension adaptors.
•Automatic arms restraints.
• Hydraulic power unit.
•Long warranty period:
5 Years warranty on lift structure(including Columns, Carriage, Lifting Arms, Top Beam, Floor Cover, Platform, Cross Beam, Car Drive-in Ramp, Scissor, Baseframe etc.);
2 Years warranty on the hydraulic parts (including cylinders, oil seal, oil hose, fitting etc.);
1 Year warranty on the spare parts, electrical components, power unit (not including consumption parts such as rubber pad).



Electrical Hydraulic Lift for Auto Garage (209CH)Model209CHStylePlaner-type Direct-drivedLifting Capacity4.0T (9,000lbs)Lifting Time52 SecondsALifting Height1815-2044mm(71 1/2"- 80 1/2")BOverall Height4231mm/4431mm(166 1/2" / 174 1/2")COverall Width3428mm(135")DDrive-Thru Clearance2528mm(99 1/2")EWidth Between Columns2850mm(112 1/4")FMinimum Pad Height90mm(3 1/2")Gross Weight701kg(1,545lbs)Motor2.0/3.0HPPacking Dimension2815 X 450 X 755 mmQTY of Container23 Units/20'GP46 Units/40'GP


EVERY PEAK LIFT IS FOR THE CUSTOMERS WHO NEED GOOD QUALITY PRODUCTS AT COMPETITIVE PRICE!
