Used Automotive Paint Polishing Room
Shandong Longxiang Machinery Co., Ltd.- After-sales Service：1 Year
- Warranty：1 Year
- Type：Preparation
- Certification：CE
- Substrate：Steel
- Brand：Longxiang Brand
Base Info
- Model NO.：LX-6200
- Coating：Powder Coating
- Airflow Direction：Cross-flow Type
- Heating Mode：Without Heating
- Paint Mist Treatment：Dry-type
- Condition：New
- Inside Dimension：6300*3450*2800mm(L*W*H)
- Outside Dimension：7550*3550*3200mm(L*W*H)
- Basement：Without Basement
- Fan System：Centrifugal Fan
- Lighting System：LED Lighting
- Voltage：380V,220V
- Total Power：6.4kw
- Usage：Car Polishing
- Name：Prep Station
- Filtering System：Fiber Glass Filter
- Glass：Tempered Glass
- Transport Package：Sea Package
- Specification：7550*3550*3200mm(L*W*H)
- Trademark：longxiang brand
- Origin：China
- HS Code：8419899090
- Production Capacity：30 Sets,Months
Description
Specification of Prep-station (LX-6200) Inside dimension 6300×3450×2800mm(L×W×H) Outside dimension 7550×3550×3200mm(L×W×H) Basement and floor Without basement,exhaust air from bottom of rear wall Ceiling system 6400×3550×520mm(L×W×H),with lights on 2 sides of roof,part of the roof with filter,other small part with air-proof seal plate Generator setting type 2 rows of pits for exhaust air, with quadrate steel frame,white color coated steel Exhaust system Generator cabin dimension:1300×1100×1900mm(L×W×H);with 1 set 5.5KW inner motor centrifugal fan with air capacity 20000m³/h,electric damper control intake and exhaust air capacity Seal type Three sides with PVC soft curtain,one side with 50mm wall panel Ceiling installation Steel rope hanging or steel pole supporting the roof(optional) Filter system Fiberglass filter Lighting system 8 units×3pcs=24×36W Control system Fan switch,lighting switch and electric damper switch Voltage frequency 380V/3PH or 220V/1PH,50HZ Roof Single iron sheet bending roof Glass Tempered glass Total power 6.4KW
