• Model NO.：JZJ-9100
• Coating：Painting
• Airflow Direction：Fully Undershot-type
• Heating Mode：Diesel
• Paint Mist Treatment：Dry-type
• Condition：New
• Color：Sea Blue, Red, Orange, White
• Motors：Proof-Explosion Motors
• Lighting：External Lighting
• Inside Dimension：6900*4000*2650(mm)
• Heating System：Diesel Oil or Eletricity
• Transport Package：Consist with International Shipping Packaging.
• Specification：CE, ISO
• Trademark：JZJ
• Origin：Yancheng Jiangsu
• HS Code：8419399090
• Production Capacity：2500 Sets,Year

17KWCabin systemWall panel  50mm EPS sandwich panel, steel sheet thickness: 0.6mmCeiling panel Galvanized steel sheet.Basement300mm depth, middle with grids, side with checkered plates. Rampthree pieces 2000*900mm rampsGlass4mm safety tempered glassWindowsSquare glass windows. Air Make-up SystemAir Inlet fan system1*7.5kw turbo fan, proof-explosion motor, Ex ratedExhausted fan system1*7.5kw turbo fan, proof-explosion motor, Ex rated Air capacity 25000m3/hAir Flowing speed0.3m/s in empty boothAir Control methodOne manual damper for air inlet and exhausted systemAir ducting8 meters air duct, one flop damper and one weather hoodPurification SystemPre-filterG3 grade, Pockets filter Ceiling filterEU5 / F5Floor filtergreen fiber glass filter / G3 gradeExhausted fan FiltersPocket filter or M green fiber glass filter and active carbonHeating SystemHeat ExchangerSUS304 material, argon arc welding.Heating burner:        RG5S diesel oil burner(gas burner for option)    Heating productivity                             260000Kcal/hSpray to baking switchPneumatic Damper Chimney ducting3 meters stainless ducting and one chimney elbowMax heating temperature80degreesHeating time5-6min(20-60degrees)fuel consumption6-8L/vehicleLighting SystemCeiling lights8 Units, each 4 * 36W Philips lamps, Total 1152 WSide lights8 Units, each 4 *20W Philips lamps, Total 800 WIllumination 1000LUXControlling systemSwitched control panel Spraying & baking switch, lighting switch, emergency stop,
breakdown alarm, failure alarm, pressure gauge

Q: Which Port of loading?

A: Mainly ship from Ningbo port / Shanghai Port/Guangzhou Port.



Q: What is your MOQ?

A: All the products can be mixed in one container with low MOQ 1pcs.



Q: What is the Lead Time?

A: Normally it needs 20-25 days.



Q: What is the Payment Terms?

A: T/T/ 30% deposit before production and 70% before delivery.



Our Service
1. 24 months warranty time
2. Customization accepted
3. OEM accepted
4. Detailed installation drawings and video will be provided. If needed, we also have special experienced installing staff can go abroad to help customers install and check spray booth.
5. Prompt after-sale service. We have established perfect after-sale service system. If needed, our staff will arrive in 72 hours to repair products.

If you have interest in any of our products, please kindly contact us. If you have anu questions or doubts, please also feel free to contact us.
