• Model NO.：3D Wheel Alignment Machine
• Certification：CE
• Communication Mode：Wire Communication
• Structure：Electronic
• Standard：Standard
• Condition：New
• Wheel Track：1200-2500mm
• Wheel Base：2000-5000mm
• Length of Beam：2600mm
• Height of Colum：1400-2340mm
• Transport Package：Export Container ,Pallet ,Disassembly with Carto
• Specification：CE, SGS, ISO
• Trademark：OEM,Captain
• Origin：Shandong, China.
• Production Capacity：196sets,Month
• Package size per unit product：200.00cm * 50.00cm * 50.00cm
• Gross weight per unit product：2500.000kg

Basic Info.

Model NO. 3D Wheel Alignment Machine Certification CE Communication Mode Wire Communication Structure Electronic Standard Standard Condition New Wheel Track 1200-2500mm Wheel Base 2000-5000mm Length of Beam 2600mm Height of Colum 1400-2340mm Transport Package Export Container /Pallet /Disassembly with Carto Specification CE, SGS, ISO Trademark OEM/Captain Origin Shandong, China. Production Capacity 196sets/Month

Packaging & Delivery

Package size per unit product 200.00cm * 50.00cm * 50.00cm Gross weight per unit product 2500.000kg

Product Description

Feature:
1. 500M pixel CMOS camera with advanced technology and latest electronic components
2. Reliable 3D image camera capture automatically
3. target without electronic parts and power instead of sensor
4. No need make any calibration after factory setting
5. Beam height adjustable
6. works on non-horizontal lift
7. automatically tracing target and display in real-time
8. No need to push-pull vehicle for measurement
9. Win XP, Win 7 system with multi-languages display
10. data update every year on internet
11. suitable for passenger car and light truck with 12"-24" rim


Measuring item	accuracy	Measuring range
Toe	±0.01" or ±0.01mm	±20"
Camber	±0.01"	±30"
Caster	±0.02"	±30"
Set Back	±0.01"	±20"
Thrust Angle	±0.01"	±20"
Wheel track	±2mm	1200-2500mm
Wheel base	±2mm	2000-5000mm
Length of beam		2600mm
Height of colum		1400-2340mm


Standard Accessory:
4 pieces of target, 4 pieces of 24" clamp, measuring beam with camera, colum, cabinet, PU unit, LCD monitor, turntable, steering wheel lock, foot brake depresser

Optional Accessory:
Tablet PC, 24" LCD monitor, 32" LCD monitor, printer, special target for height measuring, wireless kety board and mouse
