• Model NO.：MG50504
• Set Contains：32 Piece,Item
• Synchronizer Gauges：3-1,2"
• Rubber Hose：8X5X750mm
• Extension Tube：3.9X52mm, 3.9X122mm
• Cone Type Connector：8X40mm
• Tubes：10X53mm(M6X0.75), 10X60mm(M6X1.0)
• Transport Package：Blow Mold Case
• Trademark：MAGMA
• Origin：China
• HS Code：82073000
• Production Capacity：10, 000 Set,Year

Basic Info.

Model NO. MG50504 Set Contains 32 Piece/Item Synchronizer Gauges 3-1/2" Rubber Hose 8X5X750mm Extension Tube 3.9X52mm, 3.9X122mm Cone Type Connector 8X40mm Tubes 10X53mm(M6X0.75), 10X60mm(M6X1.0) Transport Package Blow Mold Case Trademark MAGMA Origin China HS Code 82073000 Production Capacity 10, 000 Set/Year

Product Description

Carburettor Synchronizer Set

This kit allows you to synchronize the values of the 4 carburettors as well as adjust and set them.
Vacuum measuring range: 0 to -70 cmHg (0 to -30 inHg).
Pressure measuring range: 0 to 14 psi (0 to 1 kg/cm2).
Set contains:
4x Synchronizer gauges with fixed plate
4x Rubber hoses 8 x 5 x 750mm
4x Adapters 53mm (M6 x 0.75)
4x Adapters 60mm (M6 x 1.0)
4x Adapters 98mm (M5 x 0.8)
4x Adapters 168mm (M5 x 0.8)
1x Adapter 55mm
4x Hose clamps with spare sealing rings

-----------------------------------------
Balancing carbs is important

Balancing or synchronising the carburettors on a multi-cylinder motorcycle is an important part of machine set-up. Out-of-synch carbs will cause an engine to cough, splutter and tick-over erratically at the best of times. But do not worry, Fuel Synchronisation Kit will help you to find balancing carbs is so easy.
