Collision Repair System (SAMPLE 3600)
Xian Foreign Trade and Economic Development Corporation- Type：Flatbed-type
- Max. Lifting Capacity：4.5T
- Certification：ISO
- Standard：Standard
- Condition：New
- Bluetooth：Not Support Bluetooth
Base Info
- Production Capacity：1000
Description
Basic Info.
Production Capacity 1000Product Description
Model: Sampe 3600
Product features
1. Unique deck design for downpulls wherever you need them;
2. Towers move 360 degrees around the frame bed;
3. Adjustable collar on tower performs both straight and angle pulls;
4. Safe and easy locking mechanism on each tower to easily adjust in locking positions;
5. Front and rear removable cross members allow access for working under vehicle;
6. Disassembly cross member add fixed points;
7. Deck length: 6000mm, deck width: 2235mm, deck height: 300mm to 1020mm;
8. Available with overhead beam, American style clamp and electric pump.
Specifications
Length^^^^^^^^^^^^^^^^^^^^...6000mm
Width^^^^^^^^^^^^^^^^^^^^^. 2235mm
Height^^^^^^^^^^^^^^^^^^^^^300-1020mm
Electric pump required^^^^^^^^^^^. 28mpa
Pneumatic pump required^^^^^^^^^^. 70mpa
Supply voltage^^^^^^^^^^^^^^^^220v/380v
Electric current^^^^^^^^^^^^^^...5a
Pulling capacity^^^^^^^^^^^^^^^100kn
Air supplied required^^^^^^^^^^^^. 0.8mpa
Radius of pulling^^^^^^^. ^^^^^^^360°
Max. Load^^^^^^^^^^^^^^^^^^^. 3000kg
Total weight^^^^^^^^^^^^^^^^^. 3200kg
