AA4c Automobile Power Performance and Chassis Dynamometer Vehicle Chassis Dynamometer

AA4C Automotive Co., Ltd.
  • Testing Equipment Type：Vehicle Sideslip Tester
  • Update Method：by Internet
  • Condition：New
  • Standard：Standard
  • Maximum Axle-Load Mass (Kg)：3000
  • Maximum Absorptivity (Kw)Range (M/Km)：160

Base Info

  • Model NO.：CTDCG-3
  • Maximum Braking Torque (N.M)：1600
  • Maximum Testing Speed (Km/H)：130
  • Transport Package：Metal Frame
  • Specification：CE
  • Trademark：AA4C
  • Origin：China
  • HS Code：8479899990
  • Production Capacity：100units,Month

Description

Basic Info.

Model NO. CTDCG-3 Maximum Braking Torque (N.M) 1600 Maximum Testing Speed (Km/H) 130 Transport Package Metal Frame Specification CE Trademark AA4C Origin China HS Code 8479899990 Production Capacity 100units/Month

Product Description

AA4c Automobile Power Performance and Chassis Dynamometer Vehicle Chassis DynamometerAA4C Automobile power performance and Chassis dynamometer Vehicle chassis dynamometer

ModelCTDCG-3CTDCG-10CTDCG-13
Maximum axle-load (kg)30001000013000
Maximum absorptivity (kw)160250300
Maximum braking torque (N.m)160025003000
Maximum testing speed (km/h)130130130
Roller diameter x length (mm)∮216×1000∮318×1000∮373×1000
Roller center distance (mm)480495600
Roller width inside/outside(mm)700/2700700/2700700/2700
Operation voltage *current96V ×35A96V ×35A96V ×35A
Power (Hz)220V ±10%  50HZ220V ±10%  50HZ220V ±10%  50HZ

Product description:



 The product description
Vehicle chassis dynamometer is mainly used for testing vehicle dynamics, emissions and fuel consumption, (used in conjunction with fuel consumption meter, fuel consumption meter etc.) , it can fulfill car economy experiment, dynamic experiment and reliability experiment. It can also test chassis output power, torque, speed, distance, acceleration time, sliding distance and other data. We have two major types: power performance dynamometer and emission performance dynamometer.


Main properties and features:

1. Through high precision dynamic balancing, surface coating roller have high joint strength, abrasion resistance, adhesion coefficient is 0.92 or higher
2. Equipped with adjustable gear wheel, in order to guarantee the front drive vehicles test do not produce lateral slip; safe and reliable
3. With fuel consumption meter, it can measure the condition of fuel consumption
4. The body is made of high quality flat MS Windows machine, ability is all ready, friendly interfaces, strong networking and it is convenient
5. Retrieve testing data, automatically print the results
