Spray Booth AA-Lx5
AA4C Automotive Co., Ltd.- Substrate：Steel
- Coating：Painting
- Heating Mode：Electric
- Condition：New
- Specification：CE
- Trademark：AA4C
Base Info
- Model NO.：AA-LX5
- Origin：China
- HS Code：9031809090
- Production Capacity：100units,Month
Description
380V,50HZ,3 phase
Wallboard: EPS colorful steel skin board, wall panel: 70mm thick, ceiling panel: 50mm thick rock-wool panel, tongue & groove style compound construction, aluminum-alloy frame, anti-flame and heat- insulation
Purification System: Dual filtering structure, the primary filter can capture granules larger than 10 μ M. Ceiling filter can capture granules bigger than 4μ M. The whole purification system has capacity of large volume of dust. Its filtering rate reaches 98%. Air pressure balance gauge, TSP≤ 1.2mg/m3
Heating SystemItaly:
Italy Riello RG3 diesel burner,
160000Kcal/h, 20N damper motor
SUS304 stainless steel heating exchanger, argon arc welding max temp: 80 tempreature, heating time: 4-5min(20-60tempreature ),
Fuel consumption: 4-5kg/vehicle
36 pcs ceiling nozzles with 2 centrifugal fans(1.5kw/set) & two corner dryers for drying water based paint
Lighting System: Ceiling Light: 32pcs 36w Philips lamp; Bottom light: 32pcs 20w Philips lamp, 1100 Lux
Controlling System: PLC digital controlling, soft touching button, spray & baking switch, light switch, emergency stop, breakdown alarm
Environmental System: Multi-layer fiberglass filter, active carbon.
