Smart Wheel Balancer with Pedal Brake
Yingkou Yuanmech Machinery Co., Ltd.- Warranty：14 Months
- Balancing Type of Wheel：Off-Car Type
Base Info
- Model NO.：B657P
- Balancing Range：Small Size Wheel
- Design Type：Horizontal Type
- Function：Dynamic Balance, Static Balance, Wheel Balance, Motorcycle Balance, Well Balanced, Auxiliary Implicit Procedure, Calibration Procedure
- Working Noise：<70db(A)
- Condition：New
- Certificate：CE Certificate
- Power：250W
- Balancing Speed：200 R,Min
- Motor Power：110V,220V,240V, 50Hz,60Hz
- Rim Diameter：10-28"
- Max Wheel Diameter：1000mm
- Max. Wheel Weight：70kg
- Rim Width：1.5-20"
- Calibration Wheel：15" Steel Rim Wheel
- Max Wheel Weight：70kg
- Machine Weight：N.W:105kg G.W:120kg
- Packing Size：1000*650*1160mm
- Optional Specifications 1：Optional Electromagnetic Brake
- Optional Specifications 2：Optional Laser Light
- Optional Specifications 3：Optional Motorcycle Adaptor
- Transport Package：Plywood
- Specification：1000*650*1160mm
- Trademark：YuanMech
- Origin：Yingkou, Liaoning, China
- HS Code：9031100090
- Production Capacity：3000PCS,Month
- Package size per unit product：100.00cm * 65.00cm * 116.00cm
- Gross weight per unit product：120.000kg
Description
1. How to make sure the calibration is performed successfully?
Use a well-balanced calibration wheel. After calibration leave the wheel on, run the wheel in Dynamic mode several times, and apply random weight both inside and outside. Check if the machine show the weight and if the weight is always at 6 o'clock position. (Please contact us if you need operation video)
2. When working table doesn't turn, how to determine if the problem comes from gearbox, motor or switch?
Disconnect belt and see if the motor can run properly. If not, test the motor itself to see clockwise rotation and anti-clockwise rotation. If motor running properly then the problem is the switch.
We have trouble shooting in details, please contact us for more information.
3. How does the wheel balancer work? What are the functions of the main components?
Piezoelectric sensor get "vibration" signal and send it to CPU. Encoder board get "position" signal and send it to CPU. CPU calculate imbalance based on these signals, wheel dimensions and balancing mode. (Please contact us if you have more questions on this topic)
