• Model NO.：T8115VF
• Origin：China
• HS Code：8460299000
• Production Capacity：10 Units,Month

Basic Info.

Model NO. T8115VF Origin China HS Code 8460299000 Production Capacity 10 Units/Month

Product Description

AA4C Line Boring Machine for Main and Camshaft Bearings
Features

This kind of line boring machine is repairing machine tools with high efficiency and high precission, They can be used for boring
Master bushing and bushing of engine & generator's cylinder bodier in automobiles, tractors and ships etc. If necessary, the
Flywheel hub bore and bushing seat hole can be also finely bored, to be supplied with following accessories: Accessories for
Centering, sectifying tool, measuring inner diameter, boring rod bracket, tool holder to increase diameter, boring tool
Micro-adjuster and for distance tool sectifying device can be provided with the main machine.


Model T8115VF T8120VF T8125VF

Range of hole diameter to be bored 36-150 mm 36-200 mm 28-225 mm
Max. Length of cylinder body to be bored 1600 mm 2000 mm 2250 mm
Main shaft max elongation 300 mm 300 mm 300 mm
Main shaft rotating speed(stepless) 30-500 rpm 30-500 rpm I: 30-150rpm; II: 93-467 rpm
Boring shaft feed 0.044, 0.167 mm/r 0.044, 0.167 mm/r 0.43; 0.085; 0.125 mm/r
Motor power 0.75/1.1 Kw 0.75/1.1 Kw 1.5 Kw
Overall dimension (L× W× H) 3500× 800× 1500 mm 3900× 800× 1500 mm 4382× 650× 1420 mm
Packing dimensions (L× W× H) 3650× 1000× 1600 mm 4040× 1020× 1600 mm 4040× 1020× 1700 mm
N. W. /G. W. 1900/2200 kg 2200/2500kg 2200/2500kg
