Automobile Vehicle Service Equipment of Motorcycle Dynamic Wheel Balancer
Yingkou Yuanmech Machinery Co., Ltd.- Warranty：14 Months
- Balancing Type of Wheel：Off-Car Type
Base Info
- Model NO.：B657
- Balancing Range：Small Size Wheel
- Design Type：Horizontal Type
- Function：Dynamic Balance, Static Balance, Wheel Balance, Motorcycle Balance, Well Balanced, Auxiliary Implicit Procedure, Calibration Procedure
- Working Noise：<70db(A)
- Condition：New
- Product Name：Motocycycle Wheel Balancing Machine
- Power：250W
- Balancing Speed：200 R,Min
- Motor Power：110V,220V,240V, 50Hz,60Hz
- Rim Diameter：10-28"
- Max Wheel Diameter：1000mm
- Max. Wheel Weight：70kg
- Rim Width：1.5-20"
- Calibration Wheel：15" Steel Rim Wheel
- Max Wheel Weight：70kg
- Machine Weight：N.W:105kg G.W:120kg
- Packing Size：1000*650*1160mm
- Optional Specifications 1：Optional Pedal Brake
- Optional Specifications 2：Optional Laser Light
- Optional Specifications 3：Optional Electromagnetic Brake
- Transport Package：Plywood
- Specification：1000*650*1160mm
- Trademark：YuanMech
- Origin：Yingkou, Liaoning, China
- HS Code：9031100090
- Production Capacity：3000PCS,Month
- Package size per unit product：1000.00cm * 650.00cm * 1160.00cm
- Gross weight per unit product：120.000kg
Description
1. What are common problem when using motorcycle adaptor?
The common problem with motorcycle/adaptor is the shaft strength. With heavy or big wheel, the thin shaft jumps during rotation, which cause a bad balancing result. (Please contact us if you have more questions on this topic)
2. How to properly mount the wheel on balancer in order to get good balancing result?
Two key points: First use the hand to assist the wheel in straight position, not tilting on the shaft.
Second when the locking nut start to engage, rotate the wheel backwards while locking, this guarantee even locking force. (Please contact us for if you need operation video)
3. How does the wheel balancer work? What are the functions of the main components?
Piezoelectric sensor get "vibration" signal and send it to CPU. Encoder board get "position" signal and send it to CPU. CPU calculate imbalance based on these signals, wheel dimensions and balancing mode. (Please contact us if you have more questions on this topic)
