• Coating：Painting
• Airflow Direction：Fully Undershot-type
• Heating Mode：Diesel
• Paint Mist Treatment：Dry-type
• Condition：New
• External Size(M)：7.0X5.6X3.5
• Internal Size(M)：6.9X3.9X2.7
• Door Width(M)：3.0
• Door Height(M)：2.66
• Air Flow (M3/H)：30000
• Inside on-Load Air Speed(M/S)：0.3-0.5
• Power (Kw)：25
• Air Ventilation(Times/H)：332
• Vehicle Suited：Saloon Car
• Color：Orange, White, Red, Blue
• Transport Package：Iron Frame Packing and Carton Packing
• Specification：20GP
• Trademark：Guangli
• Origin：Guangzhou
• HS Code：8419899090
• Production Capacity：800 PCS,Month

Basic Info.

Coating Painting Airflow Direction Fully Undershot-type Heating Mode Diesel Paint Mist Treatment Dry-type Condition New External Size(M) 7.0X5.6X3.5 Internal Size(M) 6.9X3.9X2.7 Door Width(M) 3.0 Door Height(M) 2.66 Air Flow (M3/H) 30000 Inside on-Load Air Speed(M/S) 0.3-0.5 Power (Kw) 25 Air Ventilation(Times/H) 332 Vehicle Suited Saloon Car Color Orange, White, Red, Blue Transport Package Iron Frame Packing and Carton Packing Specification 20GP Trademark Guangli Origin Guangzhou HS Code 8419899090 Production Capacity 800 PCS/Month

Product Description

Electric Car Spray Bake Paint Booth Painting Oven Booths
Product Description--Wall panel: Sandwich style, Thickness 50mm, polystyrene. Rock wool available as required.
--Basement: Steel structure, 3 rows of vein board and 2 rows of grids, full grids as optional.
--Door: 3 pcs of front door without aluminum side cover. 1 pcs of emergency door with pressure lock.
--Ramp: 2 pcs of grids.
--One 7.5kw intake fan and one 7.5kw exhaust fan.
--4m straight exhaust ducts, one 90 degree bend, and one 60 degree bend. 5m straight chimney and 2 small bends.
--Spraying/baking transition damper, automatically air controlled.
--Heat exchanger: Stainless steel. Riello G20 burner.
--Roof filter: 4 pcs of filter, mounted above support frame, which is made of steel and powder coated.
--2 pcs of floor filter and 1 pcs of outlet filter.
--Upper light: 10 sets, 4*18W per set. Side lights: 8sets, 2*18W.
--Control box: Components is import, overload, overheat, phase-lacking protection, straight driven motor.
--Automatically stop when preset time is up.
--Constant temperature spraying.
--Environmental filter: The equipment can be adopted M style activated carbon or drawer style activated carbon.

Technical Specifications	GL
External size(m)(LxWxH)	7.0×5.6×3.5
Internal size(m)(LxWxH)	6.9×3.9×2.7
Door width(m)	3.0
Door height(m)	2.66
Air flow (m3/h)	25000
Inside on-load air speed(m/s)	0.25-0.3
18	18
Air ventilation(times/h)	332
Vehicle suited	Saloon car

GuangLi Spray booth Show

Real Case






Company Profile

GZ GUANGLI EFE CO.,LTD  is a professional spray booth and car lift manufacturer in China wtih more  than 22 years technical and production experience.

Founded in 1994, Guangli has our own enterprise headquarters, which covers 58,000M ² of grounding area and 36,000M ² of building area.

GZ GUANGLI EFE CO.,LTD  is the first and the largest auto spray booth manufacturer in China, having    a good reputation among Chinese auto-maintenance enterprise. The sales volume of spray booth ranks top  in this field over years.

Equipment

We have imported a Full-auto production line and many facilities from Europe, owning the most  advanced production equipment in China.

Exhibition



Our customers



Service after the Sale
Our relationships with our customers don't stop once the product has been installed. Guangli offers many options for service and maintenance, and provides a full line of replacement parts and filters to ensure your products operate at peak efficiency.


FAQ
_{1. Q: Are you Manufacturer or Trading company?
A: We are a professional manufacturer with our own export department.
2. Q: Where is your company located? How can I visit there?
A: Our company is located in Guangzhou.All clients, from home and abroad, are warmly welcomed to visit us.
3. Q: How about the quality of the products?
A:With the advanced machines, strong and professional R &D  team and material
sources,our products are  excellent in performance and  craftsmanship.
4. Q: Can we customize our product?
A: Yes,you  can.Customized material and standard are acceptable. We can  provide different standards according to your market and favor.
5 . Q: What's the MOQ for each items?
A: We accept one piece/set each time.
6 . Q: What's the delivery tim e?
A: If the product you ordered is our standard configurations, it's 7 workdays.}
