• Model NO.：CHPLA2300
• Shearing Lift Type：0
• Condition：New
• Brand：Cherish
• Design：Two Post
• Service Environment：Indoor or Outdoors
• Unlock The Way：Manual Unlocking or Electric Unlock
• Electric Control：24V Safety Control
• Drive Mode：Hydraulic
• Construction：Two Oil Cylinders+Two Chains
• Lifting Height：1600,1800mm
• Runway Width：2115mm
• Outer Dimensions(L*W*H)：4208*2616*3109mm
• Rise/Drop Time：45s,40s
• Power：2.2kw
• Transport Package：Standard Exporting Package
• Specification：4208*2616*3109mm,4208*2616*3539mm
• Trademark：Cherish
• Origin：China
• HS Code：84289020
• Production Capacity：1000sets,Month

Basic Info.

Model NO. CHPLA2300 Shearing Lift Type 0 Condition New Brand Cherish Design Two Post Service Environment Indoor or Outdoors Unlock The Way Manual Unlocking or Electric Unlock Electric Control 24V Safety Control Drive Mode Hydraulic Construction Two Oil Cylinders+Two Chains Lifting Height 1600/1800mm Runway Width 2115mm Outer Dimensions(L*W*H) 4208*2616*3109mm Rise/Drop Time 45s/40s Power 2.2kw Transport Package Standard Exporting Package Specification 4208*2616*3109mm/4208*2616*3539mm Trademark Cherish Origin China HS Code 84289020 Production Capacity 1000sets/Month

Product Description

CHPLA2300A/B CHPLA2700

1. CE certified according to EC machinery directive 2006/42/CE.
2. Two cylinders and two chains,twice as fast as ordinary models.
3. Hydraulic driven, Chain-equalization system.
4. Single unit or share common post for multiple connected units.
5. Optional electrical or manual lock release system.
6. Powder spray coating surface treatment for indoor use hot galvanizing for outdoor use.
7. Optional manual pump on power unit in case of power off.
8. Optional 24v control box, solenoid valve and electromagnet.



Model No.	Lifting Capacity	Lifting Height	Total Height	Runway Width	Rise/Drop Time	Motor Capacity
CHPLA2300A	2300kgs	1800mm	≤3000mm	2100mm	45s/40s	2.2kw
CHPLA2300B	2300kgs	2100mm	≤3300mm	2100mm	45s/40s	2.2kw
CHPLA2700	2700kgs	2100mm	≤3520mm	2100mm	45s/40s	2.2kw

Feature:

MODEL	CHPLA2700	Load capacity	2300/2700kg
Lifting height	2100mm	Usable platform width	2100mm
Available car size	5000x1850x2050mm	Certification	CE by TUV
Power	2.2 kw	Drive mode	Hydraulic
Lifting/lowing time	45/40 s	Surface treatment	Powder coating
Operation	Key switch	Warranty	5 years for structure, 1 years for parts
Lock device	Dynamic	Lock release	Electric auto release

Contact:
We mainly manufacture 2 post car parking lifts, 4 post car parking lifts, scissor parking lifts, puzzle parking system, rotary parking system, Turntable, car stacker and so on.
