• Model NO.：ON-7445
• Design：Four Post
• Trademark：Eounice
• HS Code：8425429000
• Production Capacity：10000

Basic Info.

Model NO. ON-7445 Design Four Post Trademark Eounice HS Code 8425429000 Production Capacity 10000

Product Description

FEATURES

1. 4,500Kg (10,000LBS.) lifting capacity.
2. Reliable mechanical self-lock safety locking system.
3. Manual safety lock release.
4. Max height limit switch to ensure the cylinders work within the stroke.
5. Skid proof diamond and low-profile platforms.
6. Dual safety device: In case the primary safety locks are out of operation, the lift would also be locked automatically by the second safety device..
7. The main structural parts are welded by robot with good welding consistency, high strength and beautiful welding seam.
8. Structural parts are sprayed with imported powder, using imported spraying equipment spraying and high temperature curing, which can ensure strong adhesion, bright color and beautiful looking.

Optional manual or pneumatic rolling jack.

TECHNICAL DATA

Model	Lifting Capacity	Lifting Time	Overall Height	Lifting Height	Overall Length (Inc.Ramps)	Overall Length (No Ramps)	Overall Width	Width Between Columns	Gross Weight
ON-7445	4,500kgs (10,000LBS)	≤60S	2120mm (83 7/16")	1770mm (69 11/16")	5512mm (217")	4600mm (181 1/8")	3350mm (131 7/8")	3050mm (120 3/4")	1150kgs (2,535LBS)



PACKING AND SHIPPING:
The dimension of the four-post lift is 4700*525*600mm. Its weight is about 1050kgs.
The dimention of the control panel is 825*245*310mm. Its weight is about 25kgs

  Warranty:

 a. Steel structure warranty for five years.
 b. Hydraulic parts, electrical components, slider block,bronze bush, cable,etc warranty for one year.
 c. Consumption parts such as rubber pads etc.are not under warranty

Our Services

Our Company will Provide you some Service.

1. OEM ODM service.

2. Customized service.

3. Professional aftersales team consultant service for life long time.

FAQ

 Some buyers  may ask ?



A:You are a trading company or a factory?

A: We are a manufacturer and we have our own trade company. So pls don`t worry.



B: How long can our order be finished and delivered?

A:  Usually the lead time is within 30 days after receiving 30% deposit or L/C,



C: What is the regular color? Can I order special color which I like?

A: The regular color is Blue, Red, Yellow.

    Yes, we can also produce machines with special color according to client's request.



D: Can I order for any special size?

A:  Yes,you can.

    The size can be customized, but should be suitable for the inner size of containers.pls understand.
