Vehicle Repair Equipment & Tools

2D Automatic Measurement Wheel Balancer Machine

Yingkou Yuanmech Machinery Co., Ltd.
  • Warranty:14 Months
  • Balancing Type of Wheel:Off-Car Type

Base Info

  • Model NO.:B6552
  • Balancing Range:Small Size Wheel
  • Design Type:Horizontal Type
  • Function:Dynamic Balance, Static Balance, Wheel Balance, Motorcycle Balance, Well Balanced, Auxiliary Implicit Procedure, Calibration Procedure
  • Working Noise:<70db(A)
  • Condition:New
  • Product Name:Car Tyre Wheel Balancing Machine for Wheel Balance
  • Power:250W
  • Balancing Speed:200 R,Min
  • Motor Power:110V,220V,240V, 50Hz,60Hz
  • Rim Diameter:10-28"
  • Max Wheel Diameter:1000mm
  • Max. Wheel Weight:70kg
  • Rim Width:1.5-20"
  • Calibration Wheel:15" Steel Rim Wheel
  • Max Wheel Weight:70kg
  • Machine Weight:N.W:105kg G.W:120kg
  • Packing Size:1000*650*1160mm
  • Optional Specifications 1:Optional Pedal Brake
  • Optional Specifications 2:Optional Laser Light
  • Optional Specifications 3:Optional Motorcycle Adaptor
  • Transport Package:Plywood
  • Specification:1000*650*1160mm
  • Trademark:YuanMech
  • Origin:Yingkou, Liaoning, China
  • HS Code:9031100090
  • Production Capacity:3000PCS,Month
  • Package size per unit product:100.00cm * 65.00cm * 116.00cm
  • Gross weight per unit product:120.000kg

Description

LEDB651      B651P  Popular Choice   B652      B652E   Popular Choice  B653      B655      B655M    Popular Choice B656      B657      B657P  Popular Choice   B657PL  Popular Choice  Popular ChoiceMini-LCDB658      LCDB659      TruckB653T



2D Automatic Measurement Wheel Balancer Machine2D Automatic Measurement Wheel Balancer Machine2D Automatic Measurement Wheel Balancer Machine
2D Automatic Measurement Wheel Balancer Machine
1. How to make sure the calibration is performed successfully?

Use a well-balanced calibration wheel. After calibration leave the wheel on, run the wheel in Dynamic mode several times, and apply random weight both inside and outside. Check if the wheel balancer machine show the weight and if the weight is always at 6 o'clock position. (Please contact us if you need operation video)
2. For wheel balancer machine, what are the common causes of chasing weight problem?
The wheel is not centered properly so it wobbles during rotation which cause chasing weight.
The weight is not placed in correct position in Alu mode, especially on the inner plane.
Lost accuracy and require calibration.
3. For wheel balancer machine, what are the difference between static imbalance and dynamic imbalance?
A static imbalance exists when the tire has a heavy part. The dynamic imbalance is different. A dynamic imbalance exists when a tire has two heavy parts which are located diagonally.
4. What are the common test programs inside wheel balancer machine software?
Common tests are: piezoelectric sensor test, Encoder test, Distance/Diameter/Width measurement sensor test, keyboard test, display test, motor test (Please contact us if you have more questions on this topic)
5. What are common problem when using motorcycle adaptor?
The common problem with motorcycle/adaptor is the shaft strength. With heavy or big wheel, the thin shaft jumps during rotation, which cause a bad balancing result. (Please contact us if you have more questions on this topic)

You can press " CONTACT NOW " or " CHAT WITH SUPPLIER " to get more details.
Also by other contact ways .
