• Model NO.：CQJ-Y-2-35B
• Shearing Lift Type：Ultrathin Type
• Condition：New
• Brand：Captain
• Design：Two Post
• Lifting Height：1850mm
• Lifting Time：50-60s
• Lowering Time：40s
• Rotation Angle：90 Degree
• Weight：565kgs
• Oil Pressure：21MPa
• Motor Power：2.2kw
• Voltage：220V,380V
• Dimension：3240X500X2820mm
• Transport Package：Export Container ,Pallet ,Disassembly with Carton
• Specification：CE, SGS
• Trademark：Captain ,OEM
• Origin：Jiangsu, China.
• Production Capacity：300sets,Month

Basic Info.

Model NO. CQJ-Y-2-35B Shearing Lift Type Ultrathin Type Condition New Brand Captain Design Two Post Lifting Height 1850mm Lifting Time 50-60s Lowering Time 40s Rotation Angle 90 Degree Weight 565kgs Oil Pressure 21MPa Motor Power 2.2kw Voltage 220V/380V Dimension 3240X500X2820mm Transport Package Export Container /Pallet /Disassembly with Carton Specification CE, SGS Trademark Captain /OEM Origin Jiangsu, China. Production Capacity 300sets/Month

Product Description

CQJ-Y-2-35B Two-Post(Electric Unlocking) Lift

1.       antioxidant, environment-friendly electrostatic powder spray coating;
2.       international famous brand seal ring;
3.       top-level power unit;
4.       four protecting sets: pipeline explosion-proof valve,automatic mechanical,hydraulic self lock,rocker arm self-help lock;
5.       powerful structure design,safety factor is up to 1.6 times. Maximum lifting capacity is 1.2 times as rated lifting capacity.
6.       Safety voltage control
7.       Adjustable height and width


TypeLifting capacityLifting heightPressure pneumaticMotor powerVoltageN.WQJ-Y-2-35B3500KG189016Mpa2.2KW380V540KG
