AA4c Hydraulic 1 Post Car Lift Inground Car Lift Car Washing Lift

AA4C Automotive Co., Ltd.
  • Type：Double Cylinder Hydraulic Lift
  • Lifting Capacity：3.5T
  • Driving Type：Pneumatic
  • Certification：CE, ISO
  • Driving Motor Number of Mechanical Lift：None
  • Double Cylinder Lift Type：Planer-type

Base Info

  • Model NO.：AA-LA2800
  • Shearing Lift Type：Big Shear Type
  • Condition：New
  • Brand：AA4c
  • Design：Single Post
  • Max.Lifting Height：1850mm
  • Raising/Lowering Time：40-60sec
  • Supply Votage：380V,50Hz
  • Transport Package：Metal Frame
  • Specification：CE
  • Trademark：AA4C
  • Origin：China
  • HS Code：8425429000
  • Production Capacity：100units,Month

Description

Lifting Capacity3500KGMax.Lifting height1850mmRaising/Lowering time40-60secSupply Votage380V/50HzThe pressure of the air source when unlock 0.6-0.8Mpa(6bar-8bar)Main Unit Diameter490mmMain Unit Height2514mmMotor Speed2850 rounds/minOutput of oil pump1.6Ml/roundSet pressure of the overflow valve18MPaPump pressure20MPAWorking Pressure15MpaSolenoid valve pressureAC220 V /50 HzPower2.2kwSound level (measured at control console)≤75 dBA Load sharing max.6:4 in or against drive-on direction
