Vehicle Repair Equipment & Tools

Auto Machine Wheel Balancer PCB for Garges Replece Tire Shop

Yingkou Yuanmech Machinery Co., Ltd.
  • Warranty:14 Months
  • Balancing Type of Wheel:Off-Car Type

Base Info

  • Model NO.:B653
  • Balancing Range:Small Size Wheel
  • Design Type:Horizontal Type
  • Function:Dynamic Balance, Static Balance, Wheel Balance, Motorcycle Balance, Well Balanced, Auxiliary Implicit Procedure, Calibration Procedure
  • Working Noise:<70db(A)
  • Condition:New
  • Product Name:Tire Shop Machine Set Wheel Balancer PCB
  • Power:250W
  • Balancing Speed:200 R,Min
  • Motor Power:110V,220V,240V, 50Hz,60Hz
  • Rim Diameter:10-28"
  • Max Wheel Diameter:1000mm
  • Max. Wheel Weight:70kg
  • Rim Width:1.5-20"
  • Calibration Wheel:15" Steel Rim Wheel
  • Max Wheel Weight:70kg
  • Machine Weight:N.W:105kg G.W:120kg
  • Packing Size:1000*650*1160mm
  • Optional Specifications 1:Optional Pedal Brake
  • Optional Specifications 2:Optional Laser Light
  • Optional Specifications 3:Optional Motorcycle Adaptor
  • Transport Package:Plywood
  • Specification:1000*650*1160mm
  • Trademark:YuanMech
  • Origin:Yingkou, Liaoning, China
  • HS Code:9031100090
  • Production Capacity:3000PCS,Month
  • Package size per unit product:1000.00cm * 650.00cm * 1160.00cm
  • Gross weight per unit product:120.000kg

Description

LEDB651      B651P  Popular Choice   B652      B652E   Popular Choice  B653      B655      B655M    Popular Choice B656      B657      B657P  Popular Choice   B657PL  Popular Choice  Popular ChoiceMini-LCDB658      LCDB659      TruckB653T



Auto Machine Wheel Balancer PCB for Garges Replece Tire ShopAuto Machine Wheel Balancer PCB for Garges Replece Tire ShopAuto Machine Wheel Balancer PCB for Garges Replece Tire Shop
Auto Machine Wheel Balancer PCB for Garges Replece Tire Shop

1. How to test capacitor inside single phase motor?
Discharge the capacitor. Set the multimeter to measure resistance. Connect probes to leads of capacitor. The meter will show a reading and soon will display an open circuit (infinity). Note down the reading that was displayed for that short period. Repeat the test several times. Every test should show similar result for a good capacitor.
2. Is it necessary to do the check spin once the wheel is balanced?
Normally check spin (wheel off and on again) will give different result, most wheel balancer machine manufacturers permit tolerance 5g or even 10g. Because you can't position the wheel exactly the same as before, wheel balancer is metrological machine and it can sense tiny discrepancy. (Please contact us if you have more questions on this topic)
3. What are the recommended adaptor for balancing truck/bus wheels?
Large size cone and large size backing plate can center truck/bus wheel.
Stud hole clamp is best option to fix commercial truck/bus wheel because it simulate the wheel on the vehicle. (Please contact us for if you need operation video)
4. How to properly mount the wheel on balancer in order to get good balancing result?
Two key points: First use the hand to assist the wheel in straight position, not tilting on the shaft.
Second when the locking nut start to engage, rotate the wheel backwards while locking, this guarantee even locking force. (Please contact us for if you need operation video)
