Automatic! ! ! Auto Spray Booth
Guangzhou Baoyue Electromechanical Equipment Co., Ltd.- Certification：CCC, CE, CSA, GS, UL
- Airflow Direction：Fully Undershot-type
- Heating Mode：Diesel
- Paint Mist Treatment：Dry-type
- Brand Name：Baoyues
- Products Name：Auto Spray Booth
Base Info
- Model NO.：BY-X
- Function：Car(or Furniture)Painting and Baking
- Certificate：CE,CCS,SGS,TUV
- Service：Professional Team for Installation Abroad
- Warranty：1 Year
- Transport Package：2 Pieces,20gp
- Specification：CE, CCS, TUV, SGS
- Trademark：Baoyues
- Origin：Guangzhou, China
- Production Capacity：80 Piecescs,Month
Description
| Inside dimension | 6900 × 3900 × 2650mm (L×W×H) |
| Outside dimension | 7000 × 5350 × 3400mm (L×W×H) |
| Front door | F olding door, 4 folds, 3000×2600 mm(W×H), without frame cover, colour : white . |
| Emergency door | 1 unit, 650×1800mm (W×H), colour: white |
| Basement | Galvanized steel assemble |
| Wall Panels | Thickness:50mm, width:1150mm, tongue and groove structure, 0.376mm colour steel with polystyrene (EPS) insulation inside, colour: blue |
| Light | Ceiling l ights:8Units × 4Pcs=32Pcs × 36W,Side l ights:8Units ×2 Pcs= 16 Pcs ×18 W, with electronic ballasts, lighting boxes are powered coated. Illuminate: ≥1000LUX |
| Generator cabinet | Intake from side upper, exhaust from back upper, quadrate steel frame; white coated steel covered, filled with heat preservation material inside. |
| Intake and Exhaust system | Inlet: 2×3 KW double-intake centrifugal fans, model YDW4.5M1, air capacity for each fan: 10500m 3 /h. |
| Outlet: 1× 4KW double-intake centrifugal fan, model YDW4.5L1 , air capacity: 12500m 3 /h . | |
| Heating system | RIELLO G20 diesel burner, stainless steel heat exchanger, electric damper actuates from spraying to baking cycle. Max. heating productivity: 200000kcal/h, Max temperature: 80 degree |
| Purification system | Pre-filter, ceiling filter, fibreglass filter, activated carbon filter |
| Roof | Galvanized steel. |
| Control system | Spraying, heat spraying, baking, time setting, lighting switch, failure indicator, thermostat, power supply switch, emergency stop, temperature limit controller, exhaust with manual damper, all motors are normal start. |
| Total Power | 12KW |
