• Model NO.：T8445FCV
• Origin：Shanghai, China
• HS Code：8458990000
• Production Capacity：100units,Month

Basic Info.

Model NO. T8445FCV Origin Shanghai, China HS Code 8458990000 Production Capacity 100units/Month

Product Description

The machine is a kind of infinitely veriable speed lathe. It can fulfill the reparation of the brake drum disc and shoe of auto-mobiles from mini-car to medium heavy trucks. The unusual feature of this equipment is its twin-spindle each otherperpendicular structure. The brake drum/shoe can be cut on the first spindle and the brake disc can be cut on the secondspindle. This equipment has higher rigidity, accurate workpiece positioning and is easy to operate.


Drum dia. Capacity: Φ 180-Φ 450 mm
Disc dia. Capacity: ≤ Φ 400 mm
Spindle speed (3 steps): 30, 50, 85 r/min
Toolpost travel: 170 mm
Feed rate: 0-0.5 mm/min
Motor: 1.1 Kw / 1400 rpm
Overall dimensions (L× W× H): 820× 1080× 1180 mm
Packing dimensions (L× W× H): 1080× 820× 1280 mm
N. W. /G. W.: 320/350 kg
