Automatic Touch-Screen 4 Cylinder Gdi Fuel Injector Testing Machine Fit-G02

Wenzhou Credit Parts Co., Ltd.
  • Testing Equipment Type：Gdi Fuel Injector and Other Fuel Injectors
  • Certification：CE, ISO
  • Update Method：by Hard Disk
  • Condition：New
  • Standard：Standard
  • Temperature Scope of Operation：-10ºC~+40ºC

Base Info

  • Model NO.：FIT-G02
  • Work Voltage：220 Volts AC 50 Hz
  • Test Liquid Tank Volume：3L
  • Testing Tube Volume：200L
  • Ultrasonic Frequency：25 kHz
  • Ultrasonic Power：75W
  • Maximum Testing Number of Cylinder：4
  • Rotation Speed：0~9900 R,Min Step 50 R,Min
  • Pulse Duration：1~20 Ms Step 0.1 Ms
  • Injection Number of Times：0~9900 Step 50
  • Idle Speed：0~600 Seconds
  • Middle Speed：0~60 Seconds
  • High Speed：0~60 Seconds
  • Oil Pressure：0~800kpa(8.0kg,Cm2) (Adjustable)
  • Gross Weight：49kgs
  • Specification：540*560*800mm
  • Trademark：CreditParts
  • Origin：China
  • HS Code：9031809090
  • Production Capacity：500 Units , Month

Description

Basic Info.

Model NO. FIT-G02 Work Voltage 220 Volts AC 50 Hz Test Liquid Tank Volume 3L Testing Tube Volume 200L Ultrasonic Frequency 25 kHz Ultrasonic Power 75W Maximum Testing Number of Cylinder 4 Rotation Speed 0~9900 R/Min Step 50 R/Min Pulse Duration 1~20 Ms Step 0.1 Ms Injection Number of Times 0~9900 Step 50 Idle Speed 0~600 Seconds Middle Speed 0~60 Seconds High Speed 0~60 Seconds Oil Pressure 0~800kpa(8.0kg/Cm2) (Adjustable) Gross Weight 49kgs Specification 540*560*800mm Trademark CreditParts Origin China HS Code 9031809090 Production Capacity 500 Units / Month

Product Description

Automatic Touch-Screen 4 Cylinder GDI Fuel Injector Testing Machine FIT-G02

1. Technical Data :
Temperature Scope of Operation: -10ºC~+40ºC
Work Voltage 220 Volts AC 50 Hz. Test Liquid Tank Volume: 3L
Testing Tube Volume: 200 ml
Ultrasonic Frequency: 25 kHz
Ultrasonic Power: 75W
Maximum Testing Number of Cylinder: 4
Rotation Speed: 0~9900 r/min step 50 r/min
Pulse Duration: 1~20 ms step 0.1 ms
Injection Number of Times: 0~9900 step 50
Injection Time: Idle speed: 0~600sec
Middle speed:0~60sec
High Speed: 0~60 sec
Oil Pressure: 0~800kpa(8.0kg/cm2) (adjustable)
75 Watts /25KHz ultrasonic diagnostic and cleaning of injectors, with capacity of
stainless steel tank for 3L. Includes cables/adapters for connection of multi-purpose & CIS injectors
Micro processed equipment, totally programmable.

2.  Certificate : ISO9001 , CE
3.  Machine Picture :
Automatic Touch-Screen 4 Cylinder Gdi Fuel Injector Testing Machine Fit-G02
