Drying Chamber, Paint Booth with Heat Recovery System
Guangzhou Baoyue Electromechanical Equipment Co., Ltd.- Certification：CCC, CE, CSA, GS, UL
- Brand：Baoyues
- Airflow Direction：Fully Undershot-type
- Heating Mode：Diesel
- Paint Mist Treatment：Dry-type
- Condition：New
Base Info
- Model NO.：BY-8
- Product Name：Drying Chamber,Paint Booth with Heat Recovery Syst
- Usage：for Car(or Furniture) Painting, Baking
- Specifications：Customise Acceptable
- Certificate：CE, CCS, TUV, SGS
- Service：Professional Team for Installation Abroad
- Warranty：1 Year
- Transport Package：Sea Transport Packing 1 Set,20gp
- Specification：CE, CCS, TUV, SGS
- Trademark：Baoyues
- Origin：Guangzhou, China
- HS Code：84198990
- Production Capacity：80 Pieces,Month
Description
| Item | Detailed Specification | |||||||
| Inside dimension | 7000×4000×2800 mm (L×W×H) | |||||||
| Outside dimension | 7120×5520×3750mm(L×W×H) | |||||||
| Front door | Folding door, 3 folds, 3000×2750 mm (W×H), without frame, square window frame, orange colour, door head and two batten on both sides white colour, with safety escape door lock. | |||||||
| Emergency door | 1 units, 800×2000mm (W×H), colour: white, with safety escape door lock. | |||||||
| Basement | Galvanized steel assemble, 350mm high, galvanized steel bending support, full grilles made by flat bar 30×5 and twisted steel, galvanized, 3 ramps, 900×2500mm/pc, silver colour. | |||||||
| Wall panel | Thickness: 60mm, both sides covered by coated steel, thickness 0.6mm, with rock wool inside, colour: white. | |||||||
| Light | Ceiling Lights: 8Units×4Pcs=32Pcs×36W, both sides lights: 7Units×4Pcs=28Pcs×36W, back side lights: 4Units×4Pcs=16Pcs×36W, LED light tube. | |||||||
| Generator cabinet | Intake from back upper, exhaust from rear upper, galvanized steel frame; white powder coated panel covered, filled with heat preservation material PU inside. | |||||||
| Intake and Exhaust system | Inlet: 1×7.5KW turbo fan, Siemens motor, air capacity for each fan: 25000m 3 /h, electric damper. | |||||||
| Outlet: 1×7.5KW turbo fan, Siemens motor, air capacity for each fan: 25000m3/h, electric damper. | ||||||||
| Heating system | Italy RIELLO RG5S diesel burner, double layer stainless steel heat exchanger, pneumatic damper actuates from spraying to baking cycle. Max. heating productivity: 260000kcal/h, with heat recovery system. | |||||||
| Purification system | Pre-filter (pocket type), ceiling filter, fibreglass filter, activated carbon filter (pocket type) | |||||||
| Roof | 50mm rock wool panel. | |||||||
| Control system | Spraying, heat spraying, baking, time setting, lighting switch, failure indicator, thermostat, power supply switch, emergency stop, pressure gauge, all motors reduced-voltage starting. | |||||||
| Total power | 17KW (Power supply 1×220V, 3×380V, 50HZ) | |||||||
