• Model NO.：M3200C
• Condition：New
• Heating：Electric
• No Load Speed：0.25m,S
• Voltage：380V,3phase,50Hz
• Intake Fan：2 Sets 3kw Fan
• Exhaust Fan：1 Set 4kw Fan
• Color：Red, Blue, Yellow, Grey, White, etc
• Filter System：Ceiling and Flooring Filters
• Power：12kw
• Transport Package：Container
• Specification：26CBM
• Trademark：WINNER
• Origin：Shandong
• HS Code：8419899090
• Production Capacity：30 Sets,Month

Outside Size(mm)

7000*4000*3300 (L*W*H)

Front Door(mm)

2800*2550(W*H)

Inside Size(mm)

6900*3900*2600 (L*W*H)

Total Power(KW)

12KW for diesel burner / 36 KW for infrared heating

Wall Panel

EPS colorful steel skin panel, 50mm thick;

Tongue & groove style, anti-flame and heat-insulation.

Basement

Galvanized steel sheet and square steel pipe assembling.

2 rows of grid plates made by flat bar and round steel. 3 rows of diamond plates. 2 rows of ramps.

Intake Fans

Two sets of 3 KW fan for intaking air, air capacity 20000m³/h

Exhaust Fans

One set of 4 KW fan for exhausting air, air capacity 12500m³/h

Purification system

Pre-filter, 600G high efficiency ceiling filter, Fiberglass floor filter

Heating System

(Diesel burner or Infrared heating)

Italy Riello G20 Diesel Burner, 200000Kcal/h. Stainless steel heat exchanger,

argon arc welding. Pneumatic-damper for changing spraying and baking

Infrared heating system, 3-tubes/unit, totally 8 heating units, 24KW

Lighting System

For diesel burner heating system. Ceiling Lights: 8Units×4Pcs=32Pcs×36W.  Side Lights: 6Units×4Pcs=24Pcs×30W

For infrared heating system. Ceiling Lights: 8Units×4Pcs=32Pcs×36W

Controlling system

Power switch, Spray/baking switch, Light switch, Emergency stop, etc.

Packaging & Shipping
