The underground car lift can be desinged according to clients requirements.

Configuration:

1) Platform Material:rectangular tube + checkered iron

2) Scissor material: high strength Manganese Steel.

3) Hydraulic system: 380V/4.0Kw or as your requests.

4) High Precision Hydraulic Cylinder.

5) Piston Rod: hard chromium plating surface.

6) High-pressure oil pump

7) Hydraulic oil: summer 46#, winter 32#

8) Controller: 1 control box below, 1 control panel above platform and 1 remote controller.

Safe design :

1) Manual emergency valve, it can go down to the ground when meet power failure.

2) Explosion-proof lock valve, when the hydraulic system pipe fracture, it can cut down the channel of the oil to stop the falling.

3) The limit switch system helps car elevator to stop at accurate position.

4) Two rails column to strengthen the safety of the platform.

Our package designed to loading and unloading more easier.

Our Service :

1. Our factory can accpet design unerground car lift according to requirements. When we received your requirement, the details technical data will provide you as soon as .

2. Strict quality control system to ensure the best product for you.

3. Strict production line, make sure manufacture the goods on time.

4. Two year warranty for whole machines.

5. Providing free quick-wear part.

6. Low charge for continue maintenance when warranty is expired.

7. We can provide free training video to end clients.
