• Model NO.：UPCRCY3001
• Heating Mode：Diesel
• Paint Mist Treatment：Dry-type
• Condition：New
• Inside Dimension：6900X3900X2650mm(Lxwxh)
• Outside Dimension：7000X5300X3250mm(Lxwxh)
• Front Door：4 Folds, 3200X2600mm(Wxh)
• Emergency Door：1 Unit, 650X2000mm(Wxh)
• Basement：300mm High
• Wall Panel：50mm Rock Wool with 0.5mm Steel
• Light：32PCS Ceiling Lights, 44PCS Side Lights
• Intake System：1X7.5kw Turbo Fan
• Exhaust System：1X7.5kw Turbo Fan
• Heating System：Riello Rg5s Diesel Burner
• Transport Package：Export Container ,Pallet ,Disassembly with Carton
• Specification：CE, SGS
• Trademark：OEM,Captain
• Origin：Jiangsu, China.
• HS Code：8419899090
• Production Capacity：196sets,Month

Intake and Exhaust system
Inlet: 1×7.5KW turbo fan, power: 7.5KW, air capacity: 25000m3/h.
Outlet: 1×7.5KW turbo fan, power: 7.5KW, air capacity: 25000m3/h.Heating system
RIELLO RG5S diesel burner, stainless steel heat exchanger, pneumatic damper actuates from spraying to baking cycle. Max. heating productivity: 260000Kcal/h.Purification system
Pre-filter, ceiling filter, fiberglass filter, activated carbon filterRoof
Galvanized steelControl system
Spraying, heat spraying, baking, time setting, lighting switch, failure indicator, thermostat, power supply switch, emergency stop, hour meter, temperature limit controller,adjustable electric exhaust damper, all motors are normal start.Total power

18.5KWUNIT PRICE

Energy Saving Yellow Auto Spray Booths for Bus or car care painting, drying and Baking


Car painting, Automobile Baking, Portable Auto Spray Booths
1.Italian Riello RG5S diesel burner
 2.SUS304 Stainless steel heat exchanger
 3.Anti-flame and Heat-Insulation


Turbo Fan Electrical Heat Downdraft Auto Spray Booths For Automobile Painting, Maintenance
1) For car painting and baking
 2) maintains a high level of safety and performance together with top quality construction and materials
 3) Various systems of environmental protection are optional for customers
 4) A wide range of colors available: white,  red,  marine blue,  gray,  orange
 5) Trustworthy durability of each parts
 6) Good after-sales service



Packaging & Delivery

Packaging Detail:Export professional packages.Our packages are professional. We use the iron bracket package and it can fix the products and prevent them from broken. Moreover, we will label every components and it is easy for the customers to distinguish
Delivery Detail:To effect shipment within 7 days after deposit

Spray Booth Specifications
1.German Technology
2.spray booth professional manufacturer
3.competitive price and assure quality
4.CE approved
