Wheel Alignment (AA-WA518)
AA4C Automotive Co., Ltd.- Type：Laser Positioning System
- Certification：CE
- Communication Mode：ZigBee Wireless Communication
- Structure：Electronic
- Standard：Standard
- Condition：New
Base Info
- Model NO.：AA-WA518
- Transport Package：Plywood Case
- Specification：CE
- Trademark：AA4C
- Origin：China
- HS Code：9031809090
- Production Capacity：1000units,Month
Description
Basic Info.
Model NO. AA-WA518 Transport Package Plywood Case Specification CE Trademark AA4C Origin China HS Code 9031809090 Production Capacity 1000units/MonthProduct Description
1. Independent knowledge property right, and abundant vehicle data source, which provide long benefit for the customer;2. Advanced 8-beam CCD image measurement system, which with high precision, strong resistance for environmental interference, and good repetition;
3. All digital sensor, LED electronic gradienter structure, which keep step with numeral era;
4. Adopting wireless communication, free frequency-band could communicate freely;
5. Be economical, convenient and quick;
6. Turning measurement could adopt 8 degree no turntable measurement;
7. With three-dimensional cartoon direction teaching, which teach you how to do adjustment.
8. Simple sensor design, equipped with 17" Flat display and vogue small cabinet;
9. Install < 3.0> software on the Windows, multi-language could be selected;
| Function Feature/ Product Name | AA-WA518 | AA-WA528 | AA-WA618 | AA-WB628 | AA-WB718 | AA-WB777 | AA-WB818 |
| 8-beam CCD | yes | yes | yes | yes | yes | yes | yes |
| Communication | radio | radio | radio | bluetooth | bluetooth | bluetooth | bluetooth |
| LCD Screen for Sensor | no | no | yes | yes | yes | yes | yes |
| Measurement When Power is off | no | no | yes | yes | yes | yes | yes |
| Monitor | 17"Flat | 17"Flat | 17" LCD | 17" LCD | 19" LCD | 19"LCD | 19"LCD |
| Self-diagnose Function | no | no | yes | yes | yes | yes | yes |
| Lift Adjustment | no | no | yes | yes | yes | yes | yes |
| Run Adjustment | no | no | yes | yes | yes | yes | yes |
| Cartoon Display | 3D cartoon | 3D cartoon | 3D navigation | 3D navigation | 3D navigation | 3D navigation | 3D navigation |
| Voice Indication | yes | yes | yes | yes | yes | yes | yes |
| Software Version | Ver:2.0 | Ver:3.1 | Ver:3.1 | Ver:3.1 | Ver:4.0 | Ver:4.0 | Ver:4.0 |
| Self-diagnose Function | no | no | yes | yes | yes | yes | yes |
| Automatic Ruler | non-support | non-support | suppor | suppor | suppor | suppor | suppor |
| PDA or Multiple screen | non-support | non-support | suppor | suppor | suppor | suppor | suppor |
| Measurement | Precision | Measurement field |
| Toe | ± 0.06 ° | ±5° |
| Camber | ± 0.06 ° | ±10° |
| Caster | ± 0.08 ° | ±18° |
| King pin | ± 0.08 ° | ±18° |
| Steer angle | ± 0.5 ° | ±5° |
| Thrust angle | ± 0.06 ° | ±5° |
| Set-back | ± 0.06 ° | ±10° |
