• Model NO.：AA-3024
• Condition：New
• Transport Package：Carton
• Specification：CE
• Trademark：AA4C
• Origin：China
• HS Code：8479899990
• Production Capacity：1000units,Month

Air Operated Oil Collecting Machine
Release oil speed: 0.6-1.6L/min
Oil drain pressure: 1bar
Pot body: 24L
Automobile dawdle: 200L/min
24 l. Trailer-mounted suction equipment complete of graduated level gauge and 4 suction probes (rigid diam. 8 x 700 mm. - flexible diam. 8 / 6 / 5 x 700 mm. ). EXTRACTION IS MANUAL

Appliances to change the oil of engines, differentials, gearboxes, ect...Quickly and practically on any vehivle.
They anable extraction of hot exhausted oil (70/80 degree) by means of one of the 4 sensors provided, from the engine sump of vehicles on the ground.
After depressurizing (creating a vacum inside the tank thanks VENTURI system), they are entirely independent and need no continuous connection with the source of compressed air (compressor).
Simples to use, extraction is pneumatic. They are equippedes with a pressure relief valve set to 0.5 bar that ensures absolute safety. The outlet pip, equipped with a terminal elbow, is 1.5 m long.
The suction tube (with heat insulated handle) is 1.65 m long.
Equipped with 6 suction probes: Rigid diam. 8 mm and flexible diam. 8 / 6 / 5Mm.
