Factory Auto Garage Workshop Equipment Wheel Balancer for Car
Yingkou Yuanmech Machinery Co., Ltd.- Warranty：14 Months
- Balancing Type of Wheel：Off-Car Type
Base Info
- Model NO.：B655
- Balancing Range：Small Size Wheel
- Design Type：Horizontal Type
- Function：Dynamic Balance, Static Balance, Wheel Balance, Motorcycle Balance, Well Balanced, Auxiliary Implicit Procedure, Calibration Procedure
- Working Noise：<70db(A)
- Condition：New
- Product Name：Auto Garage Workshop Equipment
- Power：250W
- Balancing Speed：200 R,Min
- Motor Power：110V,220V,240V, 50Hz,60Hz
- Rim Diameter：10-28"
- Max Wheel Diameter：1000mm
- Max. Wheel Weight：70kg
- Rim Width：1.5-20"
- Calibration Wheel：15" Steel Rim Wheel
- Max Wheel Weight：70kg
- Machine Weight：N.W:105kg G.W:120kg
- Packing Size：1000*650*1160mm
- Optional Specifications 1：Optional Pedal Brake
- Optional Specifications 2：Optional Laser Light
- Optional Specifications 3：Optional Motorcycle Adaptor
- Transport Package：Plywood
- Specification：1000*650*1160mm
- Trademark：YuanMech
- Origin：Yingkou, Liaoning, China
- HS Code：9031100090
- Production Capacity：3000PCS,Month
- Package size per unit product：1000.00cm * 650.00cm * 1160.00cm
- Gross weight per unit product：120.000kg
Description
1. What are the recommended adaptor for balancing truck/bus wheels?
Large size cone and large size backing plate can center truck/bus wheel.
Stud hole clamp is best option to fix commercial truck/bus wheel because it simulate the wheel on the vehicle. (Please contact us for if you need operation video)
2. Which is correct? Front cone mounting or back cone mounting?
Back cone mounting is suggested, because the wheel is fixed in the way similar as it being fixed on the vehicle. (Please contact us if you need operation video)
3. Is it necessary to do the check spin once the wheel is balanced?
Normally check spin (wheel off and on again) will give different result, most manufacturers permit tolerance 5g or even 10g. Because you can't position the wheel exactly the same as before, wheel balancer is metrological machine and it can sense tiny discrepancy. (Please contact us if you have more questions on this topic)
