Portable Garage Equipment of Auto Repairing Tire Changer
Yingkou Yuanmech Machinery Co., Ltd.- Warranty：14 Months
- Structure：Vertical
Base Info
- Model NO.：C955
- Power Source：Pneumatic
- Type：Simple Disassembly
- Automatic：Semi-Automatic
- Standard：Standard
- Certification：CE
- Condition：New
- Product Name：Auto Tire Changing Equipment Tire Service Machine
- Working Pressure：8-10bar,117-145psi
- Outside Clamping：10-22"
- Inside Clamping：13-24"
- Max. Wheel Width：3-15"
- Max. Wheel Diameter：1040mm (41")
- Bead Breaker Force：2800kg
- Color：Customized Color Acceptable
- Machine Weight：N.W:250kg G.W:270kg
- Optional Specifications 1：Optional Different Kinds of Front Cover
- Optional Specifications 2：Optional Different Kinds of Pneumatic Locking
- Optional Specifications 3：Optional Different Kinds of Inflation Gun
- Optional Extra Accessory1：Motorcycle Adaptor
- Optional Extra Accessory2：Bead Blaster Function
- Optional Extra Accessory3：Leverless System
- Transport Package：Plywood
- Specification：990*760*950mm
- Trademark：YuanMech
- Origin：Yingkou, Liaoning, China
- HS Code：8479899990
- Production Capacity：3000PCS,Month
- Package size per unit product：990.00cm * 760.00cm * 950.00cm
- Gross weight per unit product：270.000kg
Description
1. Why is filter-regulator (FRL) so important?
It dry the air so there is no moisture inside pneumatic components. It lubricates the rubber seals to extend its service life. In general FRL is important to maintain long service life of the tire changer machine.
2. During mounting/demounting process, how to properly adjust mounting tool in order to release the stress on the tire bead?
The demounting head should keep a distance 2~3mm from the rim, the tool front end should be 2~3 mm from the rim edge and tool rear end should be 2-3mm above the rim edge. (Please contact us if you need operation video)
3. When working table doesn't have needed power to clamp the rim, how to trouble shooting if the problem comes from table cylinder, turning air distributor or pedal valve?
When the cylinder not strong enough, there could be air leaking. The leaking could be on the covers or internal piston. There is a systematic method to trouble shoot, please contact us if you are interested in how to trouble shoot.
