• Model NO.：T8470
• Update Method：by Hard Disk
• Max. Travel of Tool：100mm
• Color：Blue or Red
• Precision：High Precison
• Motor：1.1KW
• Weight：260kgs
• Transport Package：Plywood Case
• Specification：CE SGS ISO9001
• Trademark：HOTON
• Origin：Shandong China
• HS Code：8458190000
• Production Capacity：20 PCS,Month

Basic Info.

Model NO. T8470 Update Method by Hard Disk Max. Travel of Tool 100mm Color Blue or Red Precision High Precison Motor 1.1KW Weight 260kgs Transport Package Plywood Case Specification CE SGS ISO9001 Trademark HOTON Origin Shandong China HS Code 8458190000 Production Capacity 20 PCS/Month

Product Description

Hoton Machinery Brake Drum Lathe Machine
Applicable for repairing brake discs o flarge ,medium.
& small vehicles.and large& medium brake drums
 Available feeding in either direction. enables high efficiency
Adjustable turning depth limit with auto stop function.
Fit for more models,the max.turning diameter for brake drum
Is 700mm.
Special support enables stability for turning heavy drums
Two faces of brake disc can be turned simultaneously
Parameter of goods

Main Specifications(model)	T8470
Range of Processing Diameter(brake disk) mm	<=550
Range of Processing Diameter(brake drum) mm	220-700
Rotating Speed of Work piece  r/min	30/54/80
Max Travel of Tool(longitudinal travel)  mm	450
Max Travel of Tool(cross travel)  mm	240
Packing size  mm(L x W x H)	1115*1515*1270
N.W/G.W. kg	510/570
Motor Power kw	1.5



Contact Us:

Andy Wang  TENGZHOU HOTON MACHINERY CO.,LTD   MP:0086 13506328892 hotonmachinery.en.made-in-china.com

Company Profile:

Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008.

The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale.

Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills.
