1 Post Inground Car Lift AA-Ig3500d
AA4C Automotive Co., Ltd.- Type：Double Cylinder Hydraulic Lift
- Lifting Capacity：3T
- Driving Type：Hydraulic
- Certification：CE
- Driving Motor Number of Mechanical Lift：1
- Double Cylinder Lift Type：Planer-type
Base Info
- Model NO.：AA-IG3500D
- Shearing Lift Type：Big Shear Type
- Condition：New
- Brand：AA4c
- Design：Single Post
- Transport Package：Metal Frame
- Specification：CE
- Trademark：AA4C
- Origin：China
- HS Code：8425429000
- Production Capacity：1000units,Month
Description
Basic Info.
Model NO. AA-IG3500D Shearing Lift Type Big Shear Type Condition New Brand AA4c Design Single Post Transport Package Metal Frame Specification CE Trademark AA4C Origin China HS Code 8425429000 Production Capacity 1000units/MonthProduct Description
Max. Lifting capacity: 3500 kgLoad sharing: Max. 6: 4 in or against drive-on direction
Max. Lifting height: 1850 mm
Full Lifting (lowering) time: 40-60 sec
Supply voltage: AC380V/50Hz
Power: 3 Kw
Motor speed: 2870 rounds/minute
Output of oil pump: 2ml/r
Set pressure of the overflow valve: 130 bar
Solenoid valve voltage: AC220V/50~60Hz
Voltage of Electromagnet on mechanical lock:
AC220V/50~60Hz
Net weight: 780kg
Main body length: 420mm
Main body width: 420mm
Main body height: 2270mm
Sound level (measured at control console): ≤ 75 dBA
