Car Maker Large Spray Booth

Yancheng Sunrise Import & Export Co., Ltd.
  • Type：Coating Production Line
  • Certification：CE
  • Substrate：Steel
  • Brand：Sunrise
  • Coating：Powder Coating
  • Airflow Direction：Cross-flow Type

Base Info

  • Model NO.：M17
  • Heating Mode：Diesel
  • Paint Mist Treatment：Dry-type
  • Condition：New
  • Length：17m
  • Transport Package：Standard Export Packaging
  • Specification：20M LENGTH
  • Trademark：ORIENT
  • Origin：China
  • HS Code：84178090
  • Production Capacity：100 Per Year

Description

Construction:Painting cabin with air extractionthrough the floor,
ceiling ventilation and intake air heating
construction of housing pre-fabricated elements for installation in an existing shed
further with working pit arranged in the middle and its ventilation.
 Operational modes:Effective space:Machine space dimensions:    Thermal energy:                   Gate assembly: One main door for drive in 4,27(W) x 5,38(H) meter2 personnel doors : 0,8(W) x 2,0(H) meter, with windows.Length of connections measured over edge floor:  Exhaust air lines  approx. + 10,00 meter over edge
Suction lines   approx. +  8,00 meter over edge
Flue pipes VA   approx. +  9,00 meter over edge
( Depending on the height of hall, perhaps further channels will be necessary. )Connected loads:Approx.  50 kW
Operating voltage:   400 volts, 50 Hz.
Control voltage:   230 volts, 50 HzCar Maker Large Spray BoothCar Maker Large Spray BoothCar Maker Large Spray Booth
