• Model NO.：BY-10
• Brand：Baoyues
• Coating：Painting
• Airflow Direction：Cross-flow Type
• Heating Mode：Diesel
• Paint Mist Treatment：Dry-type
• Condition：New
• Lights：LED
• Control：Schneider
• Fan：Turbo Fan
• Transport Package：Standard Export Package
• Specification：CE, CCS, TUV, SGS
• Trademark：Baoyues
• Origin：China
• HS Code：84198990
• Production Capacity：90units,Month
• Package size per unit product：630.00cm * 345.00cm * 265.00cm
• Gross weight per unit product：900.000kg

Basic Info.

Model NO. BY-10 Brand Baoyues Coating Painting Airflow Direction Cross-flow Type Heating Mode Diesel Paint Mist Treatment Dry-type Condition New Lights LED Control Schneider Fan Turbo Fan Transport Package Standard Export Package Specification CE, CCS, TUV, SGS Trademark Baoyues Origin China HS Code 84198990 Production Capacity 90units/Month

Packaging & Delivery

Package size per unit product 630.00cm * 345.00cm * 265.00cm Gross weight per unit product 900.000kg

Product Description

The standard sanding room for car polished, sanded, base coat, top coat and painting, with light system, intake and exhaust system, control system, purification system, also can add the heating system.

Outside Dimension	7550× 3550× 3100mm(L× W× H)
Inside Dimension	6300× 3450× 2650mm(L× W× H)
Plenum Dimension	6300× 3450× 450mm(L× W× H)
Room Body	Back side with 50mm EPS wall panels, the other 3 sides with PVC curtains;
Light	Ceiling lights 8units× 4pcs=32pcs 36W, with electronic ballasts
Generator Cabinet	Exhaust from back side; square steel frame, white coated steel cover.
Intake and Exhaust System	1 unit 5.5KW double intake centrifugal fan, model YDW-4.5S, air capacity: 15500 m 3 /h, electric damper for exhausting.
Purification System	Pre-filter, high efficiency filter, exhaust fiberglass filter
Roof	Galvanized steel plates
Control System	Fan operation switch, lighting switch, emergency stop;
Install way	Suspending steel hook from roof of building or steel column supporting;
Total Power	6.7KW
